ESIE-0302 Introduction
vii
3
4
5
Part 0
1 Introduction
1.1 About This Manual
Target group This service manual is intended for and should only be used by qualified engineers.
Purpose of this
manual
This service manual contains all the information you need to carry out the necessary repair and
maintenance tasks for the EUWAC5-10FZW1, EUWA*5-24KZW1 and EUWY*5-24KZW1.
EUWAC5-10FZW1 The Daikin EUWAC5-10FZW1 air-cooled water chillers:
■ Are designed for indoor installation (centrifugal fan).
■ Are used for cooling applications.
■ Are available in three standard sizes with nominal cooling capacities ranging from 11.6 kW to
24.2 kW.
EUWA*5-24KZW1 The Daikin EUWA*5-24KZW1 air-cooled water chillers:
■ Are designed for outdoor installation.
■ Are used for cooling applications.
■ Are available in seven standard sizes with nominal cooling capacities ranging from 11.3 kW to
55.3 kW.
■ have three types of units:
EUWAN5-24KZW1 = without hydraulic module, naked model
EUWAP5-24KZW1 = with hydraulic module: pump and expansion vessel
EUWAB5-24KZW1 = with hydraulic module: buffer tank, pump and expansion vessel.
EUWY*5-24KZW1 The Daikin EUWY*5-24KZW1 heat pump water chillers:
■ Are designed for outdoor installation.
■ Are used for cooling and heating applications.
■ Are available in seven standard sizes with nominal cooling capacities ranging from 9.1 kW to
50 kW and heating from 11.9 kW to 54 kW.
■ have three types of units:
EUWYN5-24KZW1 = without hydraulic module, naked model
EUWYP5-24KZW1 = with hydraulic module: pump and expansion vessel
EUWYB5-24KZW1 = with hydraulic module: buffer tank, pump and expansion vessel.
Before starting up
the unit
Before starting up the unit for the first time, make sure it has been properly installed. See "Pre-Test
Run Checks" on page 4–3.
