General Outline ESIE-0302
1–34 Part 1 – System Outline
3
1
1
4
5
1.12 Electrical Specifications: EUWAC5-10FZW1
Electrical
specifications
The table below contains the electrical specifications
(1)
.
(1)
: The table below contains the conditions for the electrical specification values.
Model EUWAC5FZW1 EUWAC8FZW1 EUWAC10FZW1
Power supply
Phase 3N~
Frequency 50 Hz
Voltage 400 V
Voltage tolerance ± 10 %
Unit
Starting current 81 A 110 A 145 A
Nominal running
current
9.0 A 14.0 A 17.0 A
Max. running current 16.8 A 21.4 A 25.5 A
Recommended fuses 3 x 25 gG 3 x 32 gG 3 x 32 gG
Fans
Phase 1~ 3~
Voltage 230 V 400 V
Nom. running current 4.6 A 3.3 A
Max. running current
6.8A 3.4A 3.5A
Starting current DOL 20.7 A 14.9 A
Compressor
Phase 3~
Voltage 400 V
Starting current DOL
(2)
60.0 A 95.0 A 130 A
Nom. running current 6.70 A 10.7 A 13.7 A
Max. running current
(1)
10 A 18 A 22 A
Starting method Direct on line
Control circuit
Phase 1~
Voltage 230/ 24 V AC (supplied by factory installed transformers)
Recommended fuses Factory installed
Crankcase heater
(E1/2 HC)
33 W 50 W
Al values are valid for an external
static pressure of...
with factory pulley setting...
5 HP 50 Pa _
8 HP 60 Pa 0 turns open.
10 HP 72 Pa 0 turns open.
