Daikin EUWAC5FZW [206/264] Part 4

ESIE-0302 Pre-Test Run Checks

Part 4 – Commissioning and Test Run 4–3

Part 4

1 Pre-Test Run Checks

1.1 What Is in This Chapter?

Introduction This chapter contains checks you have to carry out before every test run.

Overview This chapter contains the following topics:

Topic See page

1.2–General Checks 4–4

1.3–Water Piping Checks 4–5

1.4–External Static Pressure: EUWAC5FZW1 4–8

1.5–External Static Pressure: EUWA*5-12KZW1 4–10

1.6–External Static Pressure: EUWA*16-24KZW1 4–12

1.7–External Static Pressure: EUWY*5-12KZW1 4–14

1.8–External Static Pressure: EUWY*16-24KZW1 4–16

1.9–Static Pressure of the Pump for EUWA*5-24KZW1 and EUWY*5-24KZW1 4–18

1.10–Motor Pulley Setting: EUWAC8FZW1 4–20

1.11–Motor Pulley Setting EUWAC10FZW1 4–22

1.12–Water Pressure Drop through Evaporator: EUWAC5-8-10FZW1 4–24

1.13–Water Pressure Drop through Evaporator: EUWA*5-12KZW1 4–25

1.14–Water Pressure Drop through Evaporator: EUWA*16-24KZW1 4–27

1.15–Water Pressure Drop through Evaporator: EUWY*5-12KZW1 4–29

1.16–Water Pressure Drop through Evaporator: EUWY*16-24KZW1 4–31

1.17–Setting of the Flow Switch 4–33

1.18–Air fan adjustment 4–35

1.19–Electrical Checks 4–36

1.20–Control of the function of the 4-way valve for EUWY5-24KZW1 4–37
