ESIE-0302 The Digital Controller
Part 2 – Functional Description 2–37
3
2
4
5
1
2.5 Settings: Direct and User Parameters
Direct and user
parameters
The table below describes the direct and user parameters.
How to access the
parameters
To access the parameters, proceed as follows:
Overview of the
parameters
The table below contains an overview of all the parameters. Each parameter is defined by a code and
a value.
Parameters Description Example
Direct Are used for the daily usage of
the unit.
■ To set the cooling temperature set point.
■ To read the operational information.
User Provide advanced features. Remote control
To access the… parameters Press 5 s on… A password is…
Direct
s
Not required.
Direct and user
p
Required. Use 22 as password.
Code Description Type
Default Value
Limit values
Step
value
EUWAC5-
10FZW1
EUWA*5-
24KZW1
EUWY*5-
24KZW1
:d Measurement unit (°C or °F) User 0°C 0°C 0°C 0 or 1 1
r1 Cooling tempera-
ture set point
Standard Direct 12.0°C 12.0°C 12.0°C 7.0 to 25.0°C 0.1°C
ZL option -7.0 to 25.0°C
ZH option -2.0 to 25.0°C
r2 Cooling temperature difference Direct 3.0°C 3.0°C 3.0°C 0.3 to 19.0°C 0.1°C
r3 Heating tempera-
ture set point
Standard Direct — — 30.0°C 25.0 to
48.0°C
0.1°C
ZL option
ZH option
r4 Heating temperature difference Direct — — 3.0°C 0.3 to 19°C 0.1°C
r6 Outlet water temperature Direct Read-only Read-only Read-only — 0.1
c7 Time delay between the pump
start-up and the compressor
start-up
User 15 s 15 s 15 s 0 to 150 s 1 s
c8 Time delay between the pump
shutdown and the compressor
shutdown
User 0min 0min 0min — —
c9
(1)
Total running hours of the
compressor 1
Direct Read-only Read-only Read-only — 1 h
ca
(1)
Total running hours of the
compressor 2
Direct Read-only Read-only Read-only — 1 h
