Daikin EUWAC5FZW [33/264] 24 part 1 system outline
![Daikin EUWAC5FZW [33/264] 24 part 1 system outline](/views2/1657184/page33/bg21.png)
General Outline ESIE-0302
1–24 Part 1 – System Outline
3
1
1
4
5
(1)
: The table below contains the minimum water volume settings.
Oil charge volume 2.7 l
No. of circuits 1
Pump
No. x type __ 1 x Horizontal multi-stage end-suction __ 1 x Horizontal multi-stage end-suction
Model __ CH4-30 __ CH4-30
Nominal static
height pump
__ Cooling: 205 kPa
Heating: 193 kPa
__ Cooling: 188 kPa
Heating: 180 kPa
Nominal static
height unit
__ Cooling: 151 kPa
Heating: 127 kPa
__ Cooling: 118 kPa
Heating: 100 kPa
Hydraulic components
Buffer tank __ 55 l __ 55 l
Unit water volume 3l 3l 59l 3l 3l 59l
Expansion vessel __ 12 l __ 12 l
Pre-pressure
expansion vessel
1.5 bar 1.5 bar
Safety valve __ 3 bar __ 3 bar
Dimensions
(h x w x d)
1450 x 1290 x 734 mm
Weight
Machine weight 258 kg 272 kg 284 kg 258 kg 272 kg 284 kg
Operation weight 261 kg 275 kg 343 kg 261 kg 275 kg 343 kg
Casing
Colour Ivory white / Munsell code 5Y7.5/1 / ± RAL 7044
Material Polyester coated galvanised steel plate
Sound power
level
(2)
78 dBA
Safety devices
■ Low-pressure switch
■ High-pressure switch
■ Pump motor overcurrent
■ Discharge temperature control
■ Outlet water temperature protection
■ Compressor motor overcurrent relay
■ Fan thermal protector
■ Anti-recycling and guard timer
■ Digital display controller with electronic temperature control
■ Reverse phase protector
■ Flow switch.
Model EUWYN10KZW1 EUWYP10KZW1 EUWYB10KZW1 EUWYN12KZW1 EUWYP12KZW1 EUWYB12KZW1
Setting EUWY5-12KZW1
The minimum water volume for standard thermostat difference setting 3 K
For reduced setting multiply this water volume by 3/new setting
Minimum allowable setting 0.1 K
