Daikin EUWAC5FZW [169/264] Checking the temperature sensors

Checking the Inputs and Outputs ESIE-0302

3–18 Part 3 – Troubleshooting

3.2 Checking the Temperature Sensors

Introduction

EUWAC5-10FZW1

If the cause of the problem is related to the temperature sensors, the sensors should be checked prior

to changing the controller or an output device.

Introduction

EUWA*5-24KZW1

EUWY*5-24KZW1

If the cause of the problem is related to the temperature sensors, the sensors should be checked prior

to changing the PCB or an output device.

Temperature

sensors

■ The following sensors of the EUWAC5-10FZW1 are connected to the controller: R3T/ R4T.

■ The following sensors of the EUWA*5-24KZW1 and EUWY*5-24KZW1 are connected to the I/O

PCB: R3T/ R4T and R6T/R7T/R8T.

How to check To check the temperature sensors, proceed as follows:

Step Action

■ Disconnect the sensor from the terminal connections for EUWAC5-10FZW1.

■ Disconnect the sensor from the I/O PCB for EUWA*5-24KZW1 and EUWY*5-24KZW1.

2 Measure the temperature and the resistance value.

3 Check whether the measured values correspond with the values in the appropriate table:

"Controller Sensors: R3T and R4T for EUWAC*5-10FZW1" on page 3–19.
