ESIE-0302 The Digital Controller
Part 2 – Functional Description 2–33
3
2
4
5
1
(1)
: The initialisation key can be bought as a spare part. There is one type for all micro controllers. You
have to program it yourself by configuring the settings you want on a micro controller, and then copying
these settings into the key. As soon as you have done this, you can copy the settings to other micro
controllers.
LEDs The table below contains an overview of the LEDs and their functions.
With:
p
■ The default parameters are written after pressing this key and then powering
the unit.
pu
■ The key is copied into the unit EEPROM after pressing both keys and then
powering the unit
(1)
.
Key Function
LED Function
The compressor is inactive.
Although extra load is requested, the compressor cannot start up.
The compressor is active.
Heating mode is active (only for heat pump).
Cooling mode is active.
The value on the numeric display should be multiplied by 100.
Can be used as service indication (parameter cb). See "cb" on page 2–38.
Item Description
Flashing
ON
OFF
