Functional Description ESIE-0302
2–28 Part 2 – Functional Description
3
1
2
4
5
Defrost cycle timers The table below describes the timers that are importanstet in the defrost cycle.
Tim 1
st
Defr 1/2
The minimum time that the compressor
must be switched on before the circuit
can start the defrost cycle if the ambient
temperature is under A°C.
■ Start of timer
Compressor switched on by thermostat
(DI3/4 M1/2Cdetect = closed)
AND
1
st
Defr allow 1/2=0
■ Reset of timer
Compressor switched off by thermostat
(DI3/4 M1/2Cdetect = open)
30 min
Tim 1
st
Defr_reset
1/2
The minimum time that the compressor
must be switched off before the circuit
can reset “1
st
Defr allow 1/2”.
■ Start of timer
Compressor switched off by thermostat
(DI3/4 M1/2Cdetect = open)
AND
1
st
Defr allow 1/2=1
■ Reset of timer
Compressor switched on by thermostat
(DI3/4 M1/2Cdetect = closed)
15 min
Timer Description Steps and conditions
Start-
value
Timer Description Startvalue
TimdefrMin The minimum time that a defrost cycle must be active.
(The timer only starts to count when the compressor is on.)
10 s
TimDefrMax The maximum time that a defrost can be active.
(The timer only starts to count when the compressor is on.)
10 min
TimMask The minimum time interval between the stop of a defrost cycle and the start of the
next defrost cycle.
20 min
TimComprStop The time interval that is used if the compressors stops, at the start and stop of the
defrost function.
20 s
TimComprStart The minimum time interval that is used between the start-up of compressor 1 and
compressor 2.
5 s
1
st
defrost
The first defrost that follows:
After a compressor OFF-period of 15 min
OR
After a power OFF-ON of an unit.
__
1
st
Defr allow 1/2 Below an ambient temperature of A°C, the unit is only allowed to go into 1
st
defrost
after Tim1stDefr1/2.
30 min
