ESIE-0302 Troubleshooting
Part 3 – Troubleshooting 3–41
33
4
5
1
Sensors The table below contains the settings of the sensors.
Regulator The table below contains the settings of the regulator.
Compressor The table below contains the settings of the compressor.
Code Parameter Function EUWA*5-24KZW1
Read/
write
13 Factory Air coil or ambient probe type 1 r/w
16 Factory Offset for /1 0˚C
17 Factory Offset for /2
18 Factory Offset for /3
1b Factory Digital filter 4
1v Factory Input limitation 8
1d User Measurement unit 0
Code Parameter Function
EUWA*5-
12KZW1
EUWA*16-
24KZW1
Read/
write
r1 Direct Cooling set point 12˚C 12˚C r/w
r2 Direct Cooling hysteresis 3˚C 3˚C
r5 Factory Compressor rotation __ 0
ra Factory Min. cooling set point Standard 7˚C 7˚C
ZL option -7˚C -7˚C
ZH option -2˚C -2˚C
rb Factory Max. cooling set point 25˚C 25˚C
Code Parameter Function
EUWA*5-
12KZW1
EUWA*16-
24KZW1
Read/
write
c1 Factory Min. running time 0 s 0 s r/w
c2 Factory Guard timer 6 (x 10 s) 6 (x 10 s)
c3 Factory Anti-recycling timer 24 (x 10 s) 24 (x 10 s)
c4 Factory Start delay between the two
compressors
__ 5 s
c5 Factory Stop delay between the two
compressors
__ 0 s
c6 User Time delay at start-up 0 s 0 s
c7 User ON delay pump compressor 15 s 15 s
c8 User OFF delay pump compressor 0 min 0 min r
c9 Direct Running hours compressor 1 __ __
ca Direct Running hours compressor 2 __ __
