ESIE-0302 Pre-Test Run Checks
Part 4 – Commissioning and Test Run 4–21
3
4
5
1
Symbols The table below describes the symbols.
Factory setting is pulley closed
Symbol Description
ESP External static pressure of the unit
PI Power input of the fans
AF Airflow of the fans
(1) ESP with pulley closed
(2) ESP with pulley 1 turn open
(3) ESP with pulley 2 turns open
(4) ESP with pulley 3 turns open
(5) ESP with pulley 4 turns open
(6) PI with pulley closed
(7) PI with pulley 1 turn open
(8) PI with pulley 2 turns open
(9) PI with pulley 3 turns open
(10) PI with pulley 4 turns open
