Pre-Test Run Checks ESIE-0302
4–32 Part 4 – Commissioning and Test Run
3
1
4
5
Symbols The table below describes the symbols.
(1)
: The minimum allowed waterflow of 24 HP unit is 90 l/min.
Selecting a flow outside the curves can cause damage to or malfunction of the unit. See also
minimum and maximum allowed water flowrange. See "Technical Specifications:
EUWY*16-20KZW1" on page 1–26 and "Technical Specifications: EUWY*24KZW1" on page 1–
29.
Symbol Description
PD Pressure drop through evaporator
WFE Evaporator waterflow rate
(1) For EUWY*16KZW1
(2)
EUWY(P,B)20KZW1 - EUWY(P,B)24KZW1
