DTMF MEMORY ENCODER

■ Programming a DTMF code via the microphone

[EXAMPLE]: Programming “5428AB453” into DTMF memory channel “d4.”

DTMF codes can be directly programmed via the

keypad on the microphone. The contents can be

overwritten, but cannot be cleared via the micro-

phone. See the previous page for clearing the

contents.

Ä Push [FUNC] then [➅DTMF] to turn the DTMF

memory function ON.

•“d” appears in place of the 100 MHz digit.

Å Push [FSET] to enter the programming condi-

tion.

Ç Push [Y] or [Z] to select the desired channel.

É Push the desired digit keys.

• When the first digit is input, previous memory contents are

cleared automatically.

•“E” stands for “M” and “F” stands for “#.”

• Push [Y] then [Z], and repeat this step when making a mistake.

• The S/RF indicator shows the digit group. The indication in-

creases every 6 digits.

Ñ Push [BAND] to exit the programming condition.

• The [ECLR] key cannot be used to exit. If pushed, “A” is input,

and the previously programmed data is erased. Reprogram

again in such a case.

Push

DUP+

MID

HIGH

CLR

then

FUNC

DTMF

LOW

SET

SCAN

PRIO

BAND

DTMF
