14
OTHER FUNCTIONS
61
■ Microphone [F-1]/[F-2] keys
Switches on the transceiver’s front panel can be assigned to
the microphone’s [F-1] and [F-2] keys.
➀ Turn power OFF.
➁ While pushing the desired switch on the transceiver and
[F-1] or [F-2] on the microphone, turn power ON.
• The switches’ function is programmed into the key ([F-1] or [F-2]).
• Default setting
The following functions are assigned to the [F-1]/[F-2] keys
when first applying power or after CPU resetting:
[F-1]: selects output power; push and hold to select duplex
setting
[F-2]: selects a tone function or none at all; push and hold to
start/stop tone scan
■ Display dimmer
Adjust to suit lighting conditions and personal preference.
➀ Push and hold [SET] one or more times until “d-1”–“d4” ap-
pears as follows.
• Pushing [MONI] reverses the order of selection.
➁ Rotate the tuning dial to
set the desired intensity.
• Intensity can be set from “d1”
(dark) to “d4” (bright).
➂ Push [V/MHz] to return to
normal operation.
USING
SET MODE
HI
1
9
5
The display shows the display
backlighting set to brightest.
