Icom IC-207H [75/80] Specification
![Icom IC-207H [75/80] Specification](/views2/1074416/page75/bg4b.png)
SPECIFICATIONS
16
70
General
• Frequency coverage
VERSION VHF UHF
144–148 MHz
440–450 MHz
Asia
144–148 MHz
430–440 MHz
Europe 144–146 MHz 430–440 MHz
Italy
144–148 MHz 430–440 MHz
Tx
Rx
136–174 MHz*
1
Tx
Rx
136–174 MHz*
1
400–479 MHz*
2
*
1
Guaranteed frequency coverage is 144–148 MHz.
*
2
Guaranteed frequency coverage is 430–440 MHz.
• Mode : FM, AM*
(*U.S.A. ver. only; 118–135.995 MHz)
• Antenna impedance : 50 Ω (SO-239)
• Scanning speed : 16 ch/sec. (programmed scan)
8 ch/sec. (memory scan)
• Power supply requirement : 13.8 V DC ± 15%
• Usable temperature range : –10°C to +60°C; +14°F to +140°F
• Dimensions : 140(W) × 40(H) × 184.5(D) mm
(projections not included) 5
1
⁄2(W) × 1
9
⁄16(H) × 7
1
⁄4(D) in
• Weight : 1.17 kg; 2.6 lb
Transmitter
• Modulation system : Variable reactance frequency
modulation
• Max. frequency deviation : ± 5.0 kHz
• Spurious emissions : Less than –60 dB
• Microphone impedance : 600 Ω
(8-pin modular)
• Output power and current drain:
Receiver
• Receive system : Double conversion superheterodyne
• Intermediate frequencies : 1st 46.05 MHz 2nd 450 kHz
• Sensitivity (for 12 dB SINAD) : Less than 0.18 µV
• Squelch sensitivity : Less than 0.13 µV (at threshold)
• Selectivity : More than 12 kHz/–6 dB
Less than 30 kHz/–60 dB
• Spurious response : More than 60 dB
rejection ratio
• Audio output power : More than 2.0 W at 10% distortion
with the 8 Ω internal speaker
• Current drain :
Max rated audio 1.0 A
Standby 0.8 A
CONDITION POWER
144 MHz
50 W
20 W
10 W
430(440) MHz
12.0 A
6.5 A
5.5 A
11.0 A35 W
20 W 6.5 A
10 W 5.5 A
High
Mid-Low
Mid-High
High
Mid-High
Mid-Low
All stated specifications are subject to change without notice or
obligation.
CURRENT
U.S.A.
118–174 MHz*
1
Rx
Tx
5 W 4.5 ALow
5 W 4.5 ALow
