11
DTMF MEMORY ENCODER
48
■ Transmitting a DTMF code
D Using the DTMF memory function
(automatic transmission)
The selected DTMF code is transmitted at each push of the
PTT switch when the DTMF memory encoder is turned ON.
➀ Push for 1 sec. to turn the DTMF memory encoder
ON.
•“d” appears in place of the 100 MHz digit.
➁ Push [SET] to enter the programming condition.
➂ Rotate the tuning dial to select the desired DTMF memory
channel.
➃ Push [PTT] to transmit the selected DTMF code.
• At each push of [PTT], the selected DTMF code is transmitted.
• The speaker emits the DTMF tones sent.
➄ Push for 1 sec. to cancel the function.
•“d” disappears.
Ä Push [FUNC] then [➅DTMF] to turn the DTMF
memory encoder ON.
•“d” appears in place of the 100 MHz digit.
Å
Push [FSET] to enter the programming condition.
Ç Push [Y] or [Z] to select the desired channel.
É Push [PTT] to transmit the selected DTMF
code.
• Each push of [PTT], transmits the DTMF code.
Ñ Push [ECLR] to cancel the function.
DTMF
DTMF
D Transmitting a DTMF memory channel directly
Ä Push [FUNC] then [➅DTMF] to turn the DTMF
memory encoder ON.
•“d” appears in place of the 100 MHz digit.
Å Push [DTMF-S], then push the desired DTMF
channel number.
•“0” to “9” and “A” to “D” are available for channel
numbers.
Ç Push [DTMF-S] again to deactivate the DTMF
setting.
É Push [ECLR] to turn the DTMF memory en-
coder OFF.
• When the DTMF memory encoder is turned ON con-
tinuously, each push of the PTT transmits the previ-
ously selected DTMF code.
DTMF
6
DTMF S
