PANEL DESCRIPTION
i S/RF INDICATORS (p. 22)
➥
Show the relative signal strength while receiving sig-
nals.
➥
Show the output power while transmitting.
o MEMORY INDICATOR (p. 15)
Appears when memory mode is selected.
!0 MEMORY CHANNEL READOUTS
➥
Show the selected memory channel numbers.
➥
A capital “L” appears while the frequency lock function
is in use. (p. 16)
➥
“C1” or “C2” appears while on a call channel. (p. 34)
➥
One of “L1–L5” appears when a scratch pad memory is
selected. (p. 36)
➥
One of “r1–r5” appears when a duplex scratch pad
memory is selected. (p. 36)
➥
A small “c” appears when VFO mode is selected from
the call channel or a scratch pad memory. (pgs. 34, 37)
!1 SKIP INDICATOR (p. 42)
Appears when the displayed memory channel is specified
as a skip channel.
!2 SWITCH INDICATORS
Indicate the function(s) of the front panel switches directly
below the function display.
!3 AUDIO MUTE INDICATOR (p. 56)
Appears when the audio mute function is activated via mi-
crophone control.
• This function is cancelled when any switch or control is operated.
!4 PRIORITY WATCH INDICATOR (p. 45)
Appears while the priority watch is activated; flashes while
the watch is paused.
!5 OUTPUT POWER INDICATORS (p. 22)
➥
“LO” appears for low output power. (5 W)
➥
“MID-LO” appears for mid-low output power. (10 W)
➥
“MID-HI” appears for mid-high output power. (20 W)
➥
“HI” appears for high output power.
(50 W VHF; 35 W UHF)
