13
WIRELESS OPERATION
56
D Keypad
KEY FUNCTION
SECONDARY FUNCTION (After )
FUNC
OTHER FUNCTIONS
Calls up a call channel. No secondary function.
• After :
Input the appropriate digit
for frequency or memory
channel selection.
• After :
Transmit the appropriate
DTMF code.
• After :
Transmit the appropriate
DTMF memory contents.
[0] to [9], [A] to [D] can be
used for DTMF memory.
DTMF
MEMO
DTMF
KEY
D
ENT
DEMO
Selects memory mode. No secondary function.
Selects VFO mode. Turns the one-touch PTT function ON
and OFF.
Selects high output power. No secondary function.
Selects mid-high output power. No secondary function.
Selects low output power. Turns the DTMF memory function ON.
Selects – duplex. Turns the subaudible tone encoder ON.
Selects + duplex. Turns the pocket beep function ON.
Selects simplex. Turns the tone squelch function ON.
Mutes audio signals. Starts and stops a priority watch.
AFC
CALL
1
AFC-OFF
2
MR
PTT-M
3
VFO
PGR
4
HIGH
5
C-SQL
MID
6
DTMF
LOW
7
DUP–
TONE
8
DUP
+
T-SQLS
9
SIMP
T-SQL
0
MUTE
PRIO
