DTMF MEMORY ENCODER
49
■ DTMF speed
The rate at which DTMF memories send individual DTMF
characters can be set to accommodate operating needs.
➀ Push [PWR] to turn power OFF.
➁ While pushing [SET] (far right switch), push [PWR] for 1
sec. to turn power ON and enter initial set mode.
➂ Push [SET] or [MONI] to select the “dtd” display as shown
above.
➃ Rotate the tuning dial to select the desired speed as shown
in the table below.
➄ Push [PWR] momentarily to exit initial set mode.
USING
INITIAL SET MODE
The display shows the fastest
DTMF speed is selected.
DISPLAY INTERVAL SPEED
dtd-1 100 msec. 5.0 cps
dtd-2 200 msec. 2.5 cps
dtd-3 300 msec. 1.6 cps
dtd-5 500 msec. 1.0 cps
cps=
characters/second
