QUICK REFERENCE
Quick Reference
D Charging with the BC-144/146
The optional BC-144 provides rapid charging, and the BC-146 pro-
vides regular charging of an optional battery pack with/without
transceiver. The following is additionally required:
• An optional AC adapter. (An AD-99 is supplied with BC-144/146.)
• About AD-99
Attach the spacer (Spacer B/C) to the adapter (Spacer A) with ori-
entation as illustrated in the diagram below.
• Attach the spacer (Spacer B/C) to the adapter with the orientation
of the stamp “ ” pointing up.
Check orientation
and
Spacer A
Spacer B/C
Check orientation for cor-
rect charging. (Insert
together with AD-99.)
Turn power OFF.
BC-144/146
+AD-99
