OTHER FUNCTIONS
■ CPU reset
The function display may occasionally display erroneous informa-
tion (e.g. when first applying power). This may be caused externally
by static electricity or other factors.
If this problem occurs, turn power OFF. After waiting a few seconds,
turn power ON again. If the problem persists, perform CPU reset-
ting operation as follows.
• While pushing [SQL] and [D•
CLR
], turn
power ON.
CAUTION:
Resetting the CPU returns the radio to
factory default settings.
AT
POWER ON
[SQL]
[POWER]
[D•CLR]
IC-V8_New.qxd 02.5.23 10:56 Page 56 (1,1)
