Icom IC-V8 [31/80] I battery case
![Icom IC-V8 [31/80] I battery case](/views2/1074455/page31/bg1f.png)
15
3
BATTERY PACKS
3
■ Battery case (optional for some versions)
When using a BP-208 BATTERY CASE attached to the transceiver,
install 6 AA (R6) size alkaline batteries as illustrated below.
DD
CAUTION
• Use ALKALINE batteries only.
• Make sure all battery cells are the same brand, type and ca-
pacity.
• Never mix old and new batteries.
Either of the above may cause a fire hazard or damage the
transceiver if ignored.
• Never incinerate used battery cells since internal battery gas
may cause them to rupture.
• Never expose a detached battery case to water.
If the battery case gets wet, be sure to wipe it dry before use.
IC-V8_New.qxd 02.5.23 10:55 Page 15 (1,1)
