■ Pager function
This function uses DTMF codes for paging and can be used as a
“message pager” to confirm you of a caller’s identification even
when you leave the transceiver temporarily unattended.
Optional UT-108 required
Pager selective code (push [PTT])
Beep Beep
Beep
Answer back (manual)
Beep Beep
Beep
Set both transceivers to either
code squelch or non-coded operation
Communication
