35
8
SCAN OPERATION
8
■ Priority watch
Priority watch checks for signals on “priority channels” while oper-
ating on a VFO frequency.
D Memory or call channel watch
While operating on a VFO frequency, memory or call channel watch
monitors for signals in the selected memory or call channel every
5 sec.
q Select the desired memory channel or the call channel.
w Push [D•
CLR
] to select VFO mode.
e Push [A•
FUNC
], then push [7•
PRIO
] to start watching.
• VFO is displayed, then the decimal point “.”, on the frequency read-
out blinks.
• The priority channel is monitored every 5 sec.
• When the signal is detected on the priority channel, the watching
is paused according to the setting of the scan resume condition.
r Push [D•
CLR
] to stop watching.
D Memory scan watch
While operating on a VFO frequency or the call channel, memory
scan watch monitors for signals in each memory channel in se-
quence, every 5 sec.
q Push [C•
MR
] to select memory mode, if necessary.
•“X” appears.
w Push [A•
FUNC
], then push [5•
SCAN
] to start the memory scan.
e Push [A•
FUNC
], then push [7•
PRIO
] to start the watching.
• VFO is displayed, then the decimal point “.”, on the frequency read-
out blinks.
• When the signal is detected on the priority channel, the watching
is paused according to the setting of the scan resume condition.
r Push [D•
CLR
] to stop the watching.
IC-V8_New.qxd 02.5.23 10:56 Page 35 (1,1)
