Icom IC-V8 [17/80] Accessories
![Icom IC-V8 [17/80] Accessories](/views2/1074455/page17/bg11.png)
1
1
ACCESSORIES
1
■ Accessory attachment
D Antenna
Attach the antenna to the transceiver as
illustrated at right.
Keep the jack cover attached when jacks
are not in use to avoid bad contacts.
D Belt clip
Attach the belt clip to the transceiver as illustrated below.
To attach the belt clip
To release the belt clip
IC-V8_New.qxd 02.5.23 10:55 Page 1 (1,1)
