Icom IC-V8 [4/80] Precautions
![Icom IC-V8 [4/80] Precautions](/views2/1074455/page4/bg4.png)
iii
PRECAUTIONS— continued
NEVER attempt to charge alkaline or dry cell batteries. Be
aware that external DC power connections will charge batteries
inside the battery case. This will damage not only the battery
case but also the transceiver.
DO NOT push the PTT when not actually desiring to trans-
mit.
Place the unit in a secure place to avoid inadvertent use by chil-
dren.
DO NOT operate the transceiver near unshielded electrical
blasting caps or in an explosive atmosphere.
AVOID using or placing the transceiver in direct sunlight or in
areas with temperatures below –10°C (+14˚F) or above +60°C
(+140˚F).
The use of non-Icom battery packs/chargers may impair trans-
ceiver performance and invalidate the warranty.
Even when the transceiver power is OFF, a slight current still
flows in the circuits. Remove the battery pack or case from the
transceiver when not using it for a long time. Otherwise, the bat-
tery pack or installed Ni-Cd batteries will become exhausted.
For USA only:
Caution: Changes or modifications to this transceiver, not ex-
pressly approved by Icom Inc., could void your authority to op-
erate this transceiver under FCC regulations.
IC-V8_New.qxd 02.5.23 10:55 Page iii (1,1)
