VI
QUICK REFERENCE
Quick Reference
■ Repeater operation
1. Setting duplex
➥ Push [A•
FUNC
], then [4•
DUP
] several
times to select minus duplex or plus
duplex.
• The USA version has an auto repeater
function, therefore, setting duplex is not
required.
2. Repeater tone
➥ Push [A•
FUNC
], then [1•
TONE
] several
times until “” appears, if required.
[A•FUNC]
[1•TONE]
[A•FUNC]
[4•DUP]
IC-V8_New.qxd 02.5.23 10:55 Page VI (1,1)
