39
9
SUBAUDIBLE TONES
9
■ Pocket beep operation
This function uses subaudible tones for calling and can be used as
a “common pager” to inform you that someone has called when you
were away from the transceiver.
D Waiting for a call from a specific station
q Set the operating frequency.
w Set the desired CTCSS tone frequency or DTCS code in the
SET
MODE
.
• See p. 38 for programming details.
e Push [A•
FUNC
], then push [1•
TONE
].
• Repeat several times until “” appears when CTCSS, or “” ap-
pears when DTCS is selected.
r Push [A•
FUNC
], then push [2•
P
.
BEEP
] to ac-
tivate the pocket beep function.
•“ ” appears.
t When a signal with the matched tone is re-
ceived, the transceiver emits beep tones
and blinks “ .”
• Beep tones sound for 30 sec. and “”
blinks. To stop the beeps manually, push
any key. “” continues blinking until step
y is operated.
y Push [PTT] to answer.
• “” disappears and cancels the pocket beep function automatically.
D
MR
F
D
TX
“ ” appears
MR
F
D
TX
IC-V8_New.qxd 02.5.23 10:56 Page 39 (1,1)
