Icom IC-V8 [73/80] Cloning
![Icom IC-V8 [73/80] Cloning](/views2/1074455/page73/bg49.png)
57
12
CLONING
11
12
Cloning allows you to quickly and easily transfer the programmed
contents from one transceiver to another transceiver.
D Transceiver-to-transceiver cloning
q Connect the OPC-474
CLONING CABLE
to the [SP] jack of the
master and sub-transceivers.
• The master transceiver is used to send data to the sub-transceiver.
w While pushing [A•
FUNC
] and [Y], turn power ON to enter cloning
mode (master transceiver only— power ON only for sub-trans-
ceiver).
•“CLONE” appears and the transceivers enter the clone standby
condition.
e Push [PTT] on the master transceiver.
•“CL” appears in the master transceiver’s display and two digit num-
bers show that data is being transferred to the sub-transceiver.
•“CL I
N” appears automatically in the sub-transceiver’s display and
two digit numbers show that data is being received from the master
transceiver.
r
When cloning is finished, turn power OFF, then ON again to exit
cloning mode.
D Cloning using a PC
Please refer to the HELP file that comes with CS-V8
CLONING
SOFTWARE
.
NOTE: DO NOT push the [PTT] on the sub-transceiver during
cloning. This will cause a cloning error.
AT
POWER ON
IC-V8_New.qxd 02.5.23 10:56 Page 57 (1,1)
