PAGER/CODE SQUELCH
■
Code programming
DD
Before programming
The pager and code squelch functions require ID codes and a
group code. These codes are 3-digit DTMF codes and must be writ-
ten into the code channels before operation.
q Decide the ID code of each transceiver and a group code for
your group.
w Decide whether you want to return to normal operation or code
squelch operation after a connection is made.
e Program the ID code, group code and transmit codes (other sta-
tion’s codes) as below.
DD
Code channel assignment
*
Channel CP automatically memorizes an ID code when receiving a
pager call. The contents in channel CP cannot be changed manually.
Optional UT-108 required
ID OR CODE CHANNEL “RECEIVE ACCEPT” OR
GROUP CODE NUMBER “RECEIVE INHIBIT”
Your ID code 0 “Receive accept” only
Other parties’
1–6
“Receive inhibit” should be
ID code
programmed in each channel.
Group code One of 1–6
“Receive accept” must be
programmed.
Memory space* P “Receive inhibit” only.
