63
15
OPTIONS
15
DD
OTHER OPTIONS
• HM-54/HM-46L/HM-75A/HM-131L
SPEAKER
-
MICROPHONES
Combination speaker-microphones that provide convenient oper-
ation while hanging the transceiver from your belt.
HM-75A has 4 function switches for remote control capabilities.
HM-131L has moisture proof construction.
• HM-128L
EARPHONE
-
MICROPHONE
You can clip the microphone with PTT switch to your lapel or
breast pocket.
• HS-51
HEADSET
Allows you hands-free operation. Includes VOX, PTT and “one-
touch” PTT with time-out timer.
• MB-68/MB-74/MB-87
BELT CLIPS
MB-68: Same as that supplied with the transceiver.
MB-74: Exclusive alligator-type belt clip.
MB-87: Swivel belt clip
• OPC-474
CLONING CABLE
For cloning between transceivers.
• SP-13
EARPHONE
Provides clear receive audio in noisy environments.
HM-131L HM-75A
HM-128L HS-51
HM-46L
