Stomer SMS-1500 [10/100] English

MITER SAW

User’s Manual

Intended use

This miter saw is designed for cross-cutting of timber and

plastic.

Do not use the saw to cut ﬁ rewood, metal or masonry.

SPECIFICATIONS

Voltage: 230 V

Power input: 1500 W

No load speed: 4500 min

-1

Saw blade

dimensions:

254х30х2,8 mm

Cutting capacity

miter 90°, bevel 90° - 130 x 75 mm

miter 45°, bevel 90° - 90 x 75 mm

miter 90°, bevel 45° - 130 x 50 mm

miter 45°, bevel 45° - 90 x 50 mm

Weight: 18 kg

DESCRIPTION

1. Safety lock

2. Handle

3. On/Off switch

4. Machine head

5. Saw blade

6. Hinged saw blade guard

7. Rear fence

8. Rotary table

9. Base plate

10. Lock screw

11. Wrench

12. Wrench

13. Bevel lock knob

14. Saw blade bolt

15. Saw blade cover

16. Lock pin

17. Screw

18. Chip extractor

SAFETY INSTRUCTIONS

• Do not use the saw to cut ﬁ rewood, metal or masonry.

The tool must be used only for its prescribed purpose.

Any use other than those mentioned in this Manual will

be considered a case of misuse. The user and not the

manufacturer shall be liable for any damage or injury

resulting from such cases of misuse. The manufactur-

er shall not be liable for any changes made to the tool

nor for any damage resulting from such changes.

• Read the manual carefully before use or ensure that

the operator read it and is adequately trained in the

use, adjustment and operation of the machine.

• Even when the tool is used as prescribed it is not pos-

sible to eliminate all residual risk factors. The following

hazards may rise in connection with tool's construction

and design.

- Contact with the blade.

- Kickback of workpiece and parts of workpiece.

- Blade fracture.

- Catapulting of blade pieces.

- Damage to hearing if effective ear defenders are not

worn.

- Harmful emissions of sawdust when the machine

is used in closed rooms. Beech and oak dusts are

especially detrimental to health and therefore may be

worked only with dust collector.

Always use supplementary dust extraction where pos-

sible.

Select saw blades in relation to the material being cut.

Dimensions of the blade must correspond with param-

eters of the tool, do not use any adapters. Do not use

blades of High Speed Steel (HSS blades), grinding/

cutting discs. Use only blades which conform to EN

847-1.

• Observe the maximum speed marked on the blade.

• Note the direction of rotation of the motor and the

blade. Saw blades shall be carried in a holder wher-

ever possible.

• Wear gloves when handling saw blades and rough ma-

terials.

• Make certain that the saw blade does not touch the

rotary table in any setting. To do so, pull out the power

plug and tilt the saw blade by hand into the 45° position

and the 90° position.

• Never use a cracked or distorted saw blade. Only use

sharp blades.

• Always remove the plug from the mains socket before

making any adjustments or maintenance, including

changing the blade.

• Do not slow or stop a blade with a piece of wood. Let

the blade come to rest naturally

• The use of any extension cord will cause some loss

of power. To keep power loss to a minimum and to

prevent tool overheating, use an extension cord that is

heavy enough to carry the current the tool will draw.

• When using extension cord on the reel, unwind it com-

pletely.

• Do not abuse power cord. Check it regularly. Never

use a faulty or damaged power cord.

• The machine must be connected to a 230 V socket-

outlet with a minimum 10 A fuse. When operating out-

doors, use residual current device (30 mA maximum).

• Do not operate in rain or snow, in humid places. Keep

your work area tidy. Rags, cloths, cord and string and

the like should never be left around.

• Ensure that there is adequate general or localized

lighting.

• Never saw near combustible liquids or gases.

• Dress properly. Do not wear loose clothing or jewellery.

Keep your hair, clothing and gloves away from mov-

ing parts. Loose clothes, jewellery or long hair can be

caught in moving parts.

• Ensure that the machine is always ﬁ xed to a bench,

whenever possible. Never operate your miter saw on

the ﬂ oor or in a crouched position. Failure to heed this

warning can result in serious personal injury.

• Do not let anyone under 18 years old operate this saw.

Children should keep away from the operating saw.

English
