Aten CCVSR [110/131] Compatible products

CCVSR User Manual

100

USB Authentication Key Specifications

Compatible Products

For a list of compatible products, refer to the “Specification” tab of the CCVSR

page on the ATEN website.

Linux Installation

When installing or uninstalling the CCVSR software on a computer running

Linux, use the following commands:

Linux installcommand:> sudo ./vlsman.run

Linux uninstall command:> sudo /usr/local/bin/ccvsr/uninstallvlsmon

Function Key

Environment Operating Temp.

0–40

Storage Temp.

-20–60

Humidity 0–80% RH, Non-condensing

Physical

Properties

Composition Metal and Plastic

Weight 14 g

Dimensions 8.36 x 2.77 x 1.37cm
