![Aten CCVSR [83/131] Backup restore](/views2/1977519/page83/bg53.png)
Chapter 8. System
73
Backup & Restore
The Backup & Restore page is used to Backup and Restore system
configuration settings and user account information to/from a file or system
created Checkpoint. There are two sections:
Backup
To create a backup file, click Backup to save the file. A window will pop-up to
ask you to enter a password.
Leave the Password field blank if you do not want to use a password. Press OK
to backup the system configuration. The saved data file contains the current
system configuration and all user account information.
Restore
To restore data,
1. Select where you are restoring the configurations from by selecting from
the drop-down menu. Select between Restore from a backed-up file or
Restore from a checkpoint.
2. For back-up file, click and select a file.
