Aten CCVSR [46/131] Click the open in new window icon to enter single port mode

CCVSR User Manual

Single Port Mode

Click the Open in new window icon to enter Single Port Mode.

The window also displays the Recorded Time, Resolution, Logged in

Username.

Click for full-screen mode. Press Esc to quit full-screen mode.

Click to exit Single Port Mode.

4 Playback from Click this for a drop-down menu. The option allows you to

choose when you wish to play the video log from.

5 Open in new

window

Click this if you wish to view this port in a new window.

Refer to Single Port Mode on page 36.

6 Port No. This displays the port number of the liveview.
