CCVSR User Manual
52
Authentication
The Authentication sub-menu includes settings of AD/LDAP and RADIUS.
AD / LDAP Settings
To allow authentication and authorization for the Video Log Server via AD /
LDAP, refer to the information in the table, below:
Item Action
Enable Check the Enable checkbox to allow AD / LDAP authentication
and authorization.
LDAP Type Click the drop-down menu to select Preferred or Alternate LDAP.
Server IP Fill in the IP address, you can use the IPv4 address, the IPv6
address or the domain name in the LDAP Server field.
Port Fill in the port number.
Checking Server requires secure connection (SSL), the default
port number is 636.
Otherwise, the default port number is 389.
Timeout Set the time in seconds that the Video Log Server waits for a
reply before it times out.
Admin DN Consult the AD / LDAP administrator to ascertain the appropriate
entry for this field. For example, the entry might look like this:
ou=kn4132,dc=aten,dc=com
Admin Name Key in the LDAP administrator’s username.
Password Key in the LDAP administrator’s password.
Search DN Set the distinguished name of the search base. This is the
domain name where the search starts for user names.
