Chapter 1. Introduction
5
Requirements
Computer
Systems that the CCVSR will be installed on should meet the following
requirements:
Server Hardware Requirements
CPU: Intel Xeon D-1527 4 cores 2.2 GHz or equivalent
Memory: 8 GB or above
Hard drive (for CCVSR): 4 GB or above
Network: 1 Gbps
Client Hardware Requirements
CPU: Intel Core i5-7600 4 cores 3.5 GHz or equivalent
Memory: 6 GB or above
Network: 1 Gbps
Operating System Requirements:
Windows: 10, 8, 7 or the following versions of Linux
VSR Viewer (Java-based application for video playback on a client
computer) Requirements:
JRE 8 or Zulu OpenJDK 8 FX (Windows only)
OS Version Type Kernel
Ubuntu 16.04 X86 4.10.0-28
Ubuntu 16.04 X64 4.8.0-36
Ubuntu 18.04 X64 4.19
Red Hat Enterprise Linux 7 X64 3.10.0
CentOS 7.4 X64 3.10.0-693
CentOS 7.5 X64 4.18.11-1
Debian 8.8 X64 3.16.0.4
Fedora 24 X32 4.5.5-200
Fedora 24 X64 4.5.5-200
OpenSUSE 13.2 X32 3.16.6
OpenSUSE 13.2 X64 3.16.6
