Chapter 9. Logs

Search Logs

The Search function allows you to do a general search or an advanced search.

and Advanced Search.

General Search

For a general search, you can search according to the Description or User:

1. Click the button for a drop-down menu.

2. Select Description or User. The search field will display the selection.

3. Enter the information you wish to search for in the entry field and click the

button.

Advanced Search

For an advanced search:

1. Click the button for a drop-down menu.

2. Select Advanced Search for the pop-up window below:
