Aten CCVSR [47/131] Chapter 6

Chapter 6. Device Management

Chapter 6

Device Management

Overview

The purpose of the Device Management page is to add KVM devices and

configure ports through which the Video Session Recording Software can

record video logs. The Device Management page opens the main page showing

a list of KVM devices that have been added:

Port List

A port list is available on the lower half of the Device Management page.

Checking a KVM device will display all the device’s ports in the port list as

shown:
