Chapter 4. Playback
29
Import Video
The VSR allows you to import video log files from different VSR servers.
Recorded videos are typically saved in a directory named “vls_data” as *.dat
files. This directory can be in a local drive or a network folder in your
configurations in System > Recording (Recording, page 75).
A few examples are listed below:
C:\vls_data (local drive C:\)
D:\vls_data (local drive D:\)
\\10.0.8.168\sharerecording\vls_data (network folder)
To import saved files from any computer running as a VSR server, open a
command prompt by clicking the Start Menu – Run, type CMD and click OK.
Use the following command line formula to import the video log files (.dat):
vsrImport <Destination DB file> <Source Path for VSR Data file> 0
<Destination path>
