Aten CCVSR [43/131] Modify favorite

Chapter 5. Liveview

To remove a device or a port from the list, check the checkbox in the right

panel and click the button.

You may use the filter to refine your search.

On the right panel, you may also click and drag the devices/ports to

rearrange the order of the added devices/ports.

4. When completed, click the Save button. Click the Cancel button to cancel

the modification. The added favorite will be displayed in the Favorite List

panel.

Modify Favorite

To modify the favorite, click the name of the favorite and modify as described

in Create Favorite above.

Delete Favorite

To delete a favorite, click the icon and click the Save button:
