Aten CCVSR [129/131] Offline upgrade failure
![Aten CCVSR [129/131] Offline upgrade failure](/views2/1977519/page129/bg81.png)
Appendix B
119
Offline Upgrade Failure
If the offline upgrade fails, it may be due to the key upgrade file
(KeyUpgrade.dat), having become corrupted during the file transfer process.
There are two ways to proceed:
When the key upgrade file is downloaded, an email is sent to the dealer/
distributor containing the particulars, along with a copy of the upgrade file
in case there was a problem with the original file transfer – as shown in the
example below:
Offline upgrade email response:
Your CC-Authentication key's upgrade data file is
attached. Please upgrade your CC-Auth key with the
attached file.
Key Info:
* F/W Version: 2.1.204
* Serial number: 0917280288
License Upgrade Info:
* From 512 to 513 concurrent nodes
Confirmation Info:
* Username: newname
* Password: 1123091022112900
If you have any problem with upgrading your CC-
Authentication key's license, please confirm it online
at http://xxx.xxx.x.xxx using the username and
password above.
You can repeat steps 11 (Run the Key Status Utility) and 12 (Click
Upgrade) – this time using the copy of the key upgrade file
(KeyUpgrade.dat) that was attached in the dealer/distributor email.
If the above fails to resolve the problem, information contained in the
Offline email upgrade response can be used to try an online upgrade.
Either the dealer/distributor can provide the end user with the
authorization details, or the end user can give his key to the dealer/
distributor.
