CCVSR User Manual

118

13. In the License Upgrade panel, click Upgrade.

14. In the dialog box that comes up, navigate to the upgrade file

(KeyUpgrade.dat) and select it.

 Once you click Open, a window pops up stating that the upgrade was

successful.

 The figure for the number of licenses in the License Information panel

changes to reflect the upgrade.
