CCVSR User Manual
6
KVM over IP Switch
Computers to be recorded by the Video Session Recorder must be connected
to a port on a KVM over IP Switch* (refer to the Specification section on the
CCVSR product page).
Note: Computers connected to cascaded KVM switches are not supported.
Browsers
Supported browsers for users that log into the CCVSR include the following:
Bandwidth Requirement
Text Mode = On, 1G Bandwidth
Note: 1. Numbers above are for reference only, actual bandwidth requirement
may vary (e.g. resolution, KVM model, KVM settings, Operations
from a remote server, etc.).
Browser Version
Microsoft Edge 44.18362.449 or later
Internet Explorer 11.0.9600 or later
Chrome 69.0.3497.100 or later
Firefox 62.0.3 or later
General Operations
(e.g. settings configuration, file
editing, etc.)
Surveillance
(e.g. NVR, playing videos, etc.)
KN8164V
(1080P)
3.37 Mbps / Channel
1 hour video size: 296 MB
44.6 Mbps / Channel
1 hour video size: 4 GB
CN8000A
(1080P)
12.40 Mbps/Channel
1 hour video size: 599 MB
32.4 Mbps / Channel
1 hour video size: 1.7 GB
CN9950
(4K)
17.2 Mbps / Channel
1 hour video size: 1.56 GB
189 Mbps / Channel
1 hour video size: 17.2 GB
CN9950
(1080P)
11.1 Mbps / Channel
1 hour video size: 0.93 GB
208 Mbps / Channel
1 hour video size: 17.5 GB
