Chapter 1. Introduction
3
Features
Records user sessions from BIOS-level when users access ATEN KVM
over IP switches and serial console servers locally
1
or remotely
Simultaneously records, streams and plays the operation of multiple KVM
over IP Switches
Supports high quality video recording – with video resolutions up to 4096
x 2160
2
Logs keystrokes, mouse clicks, and audio operations during video
recording sessions
Proprietary video player with format and password-protected video export
function for enhanced security
LiveView function to provide live-video surveillance for direct monitoring
of operations and changes made on servers or the connected devices
3
Intuitive User Interface with HTML5 to deliver friendly user experience
Continuous recording even without opening WinClient/JavaClient
4
Access control to grant or restrict user access with IP & MAC address
filter, and configurable failed login attempts and lockout
Configurable user and group permissions
TLS v1.2 data encryption (AES-256 bit supported) and RSA 2048-bit
certificates to secure user logins from browser
Port level permissions – users can only view ports they have been
authorized to access
Easily search through captured sessions for incident investigation
Advanced search with time, port name, and username for precise results
Flexibility in saving recorded videos in local hard drives, secondary
CCVSR servers, network attached storage (NAS) devices, or archive in
Archive server
Supports up to 3 secondary CCVSR servers for storage expansion, load
balance, and service failover
Supports self-signed certificates and certificates signed from third-party
authorities (CA)
Third-party remote authentication supports: RADIUS, LDAP, LDAPS and
Active Directory
