CCVSR User Manual
4
Centralized role-based (Super Administrator & User) policy for user
access privilege control
System event notification via SMTP email, SNMP trap and Syslog support
Supports device level event logs
Note: 1. Available on specific models only, please check specification.
2. Compatible KVM with 4K support is required.
3. Up to 20 KVM sessions with resolution 1920 x 1080 or 4 KVM
sessions with resolution 4096 x 2160 (Text Mode = On, Bandwidth =
1G, Scenario = surveillance) can be recorded/streamed
simultaneously when the hardware requirements are met (see
Requirements, page 5). Up to 64 KVM devices can be supported by
one CCVSR.
4. CN9950, CN9600, CN9000, CN8600, CN8000A, RCMDP101U,
RCMDVI101, RCMVGA101, RCM101D, and RCM101A only.
