CCVSR User Manual

After setting up your favorite, clicking the display list drop-down menu will

show the favorites in the list.

Select a favorite to only view ports in the favorite on the centralized view.

Rotate / Pause Pages

If the source ports exceed the number of display for a layout, CCVSR will

automatically rotate through the displayed ports page by page. Click the or

icons to respectively begin or pause the rotation.

Layout

You can change the layout of the centralized view by clicking the layout button

and select a desired layout choice.

By default, Auto is selected. A range of options can be selected as shown in the

diagram above.
