CCVSR User Manual
114
Performing the Upgrade
After the dealers/distributors place the upgrade orders with an Altusen sales
representative, they receive a confirmation and authorization email from
ALTUSEN, for example:
Your order is ready to be processed. Please go to http://xxx.xxx.x.xxx to
upgrade your key's license.
Login Information:
Username: myname3
Password: mypassword3
Order Information:
Order ID: 1017000750 (authorized number: 1605991978). This order
requests 1 more node(s)
To perform the upgrade, do the following:
1. Follow steps 1 – 3 given for the Online Upgrade (see page 109).
2. When the upgrade Login screen comes up, log in with the Username and
Password provided in the authorization email.
