CCVSR User Manual

This is the file that you give to the third party CA to apply for their signed

SSL certificate.

5. After the CA sends you the certificate, save it to a convenient location on

your computer. Click to locate the file; then click Upload to store it on

the CCVSR.

Note: When you upload the file, the CCVSR checks the file to make sure the

specified information still matches. If it does, the file is accepted; if not,

it is rejected.

If you want to remove the certificate (to replace it with a new one because of a

domain name change, for example), simply click Remove.
