Konica Minolta EP1050 [100/131] When an indicator lights up
![Konica Minolta EP1050 [100/131] When an indicator lights up](/views2/1122092/page100/bg64.png)
1139O0670A
Remove any sheet of paper from
the Transport Section.
3
2. Detailed Instructions for Indicator Lights
1142O073AA
Holding up the Fusing Unit, pull
out the sheet of paper .
2
1142O074AA
Open the Right Door.
Then pull out the sheet of paper
from the Manual Bypass Port.
4
1142O075AA
Pull out the sheet of paper from
the Paper Take-Up Section.
Close the Right Door.
5
6
Chapter 5
When an Indicator Lights Up
88
