![Konica Minolta EP1050 [4/131] Chapter 3 making copies 25](/img/pdf.png)
Konica Minolta EP1050 [4/131] Chapter 3 making copies 25
![Konica Minolta EP1050 [4/131] Chapter 3 making copies 25](/views2/1122092/page4/bg4.png)
Chapter 3 Making Copies 25
1. Copying Overview 26
2. Copying Procedure
Placing Originals 28
Checking the Copy Paper Size and Selecting the Paper
Source 33
Zoom Ratio
• Types of Zoom Ratios 34
• Auto Size Mode 37
• Zoom Ratio Table
(Orignal Size to Copy Paper Size) 39
Image Density 40
Book Copying 42
Finishing Modes
• Finishing Modes 44
• Selecting the Finishing Modes 45
• Auto Dual Function 46
Number of Copies 47
Starting the Copy Cycle 48
Manual Bypass Copying 49
Contents
iv
